hot sale 15ton /16ton FD150 diesel forklift truck 15 ton heavy diesel forklift with cabin

China hot sale 15ton /16ton FD150 diesel forklift truck 15 ton heavy diesel forklift with cabin supplier
hot sale 15ton /16ton FD150 diesel forklift truck 15 ton heavy diesel forklift with cabin supplier hot sale 15ton /16ton FD150 diesel forklift truck 15 ton heavy diesel forklift with cabin supplier hot sale 15ton /16ton FD150 diesel forklift truck 15 ton heavy diesel forklift with cabin supplier

Large Image :  hot sale 15ton /16ton FD150 diesel forklift truck 15 ton heavy diesel forklift with cabin

Product Details:

Place of Origin: CHINA
Brand Name: BENE
Certification: CE
Model Number: FD150

Payment & Shipping Terms:

Minimum Order Quantity: 1unit
Price: 55000USD---75000usd per unit
Packaging Details: nude
Delivery Time: in available
Payment Terms: L/C, T/T
Supply Ability: 99units per month
Contact Now
Detailed Product Description
Engine: YUCHAI Mast Height: 3500mm
Load Center: 900mm Transmission: Hydraulic
Fork Size: 1800mm

BENE 15ton /16ton FD160 diesel forklift truck 16 ton heavy diesel forklift for sale

Engine: 15 ton diesel forklift truck use Yuchai Engine, low oil consumption, high quality turbocharged engine, good power performance, big torque reserves, has strong power, energy conservation and environmental protection

Steering axle: 15 ton diesel forklift truck adopt transverse oil cylinder type steering bridge, full-hydraulic steering, flexible and light, reliable
Transmission & torque convert: 15 ton diesel forklift truck matched with imported technology, reliable performance, convenient maintenance, smooth transmission, and convenient operation

Hydraulic system: 15 ton diesel forklift truck has double pump confluence, small system flow, low power consumption, reliable performance, excellent operating performance
Pipeline: high pressure oil line impact resistance, wear resistance and long service life
Tyre: sino-us joint brand, resistant to wear and sting, high strength tyres, bear heavy loaded - safe and reliable
Fork: use famous brand Fork, with hydraulic fork positioner, easy operation and reduce drivers’ labor intensity
Mast: 3.5-6m box-type internal-external mast, special all-round roller bearings, increase lifting performance

Item Specification Unit
General 1 Model   FD150
2 Power Type/model   Diesel
3 Rated Capacity Kg 15000
4 Load Center mm 900
Dimensions 5 Lift Height mm 3500
6 Fork Size(LxWxT) mm 2000×220×90
7 Fork Spread(outside)(Min./Max) mm 540/2260
8 Mast Tilt Angle(F/R) deg 6°/12°
9 Fork Overhang mm 800
10   Length without forks mm 5400
11 Overall Width mm 2550
12 Mast Lowered Height mm 3460
13 Overhead Guard Height mm 3300
14 Outer turning Radius   mm 5050
Performance 15 Speed(Unload/Load) Travel km/h 30/26
16 Lifting mm/s 300
17 Max.gradeability(Load) % 20
18 Max.drawbar pull(Load) KN 120
19 service Weight kg 21000
Wheels&Tires 20 Tire Front   4×12.00-24-18PR
21 Rear   2×12.00-20-18PR
22 Tread Front mm 1850
23 Rear mm 2130
24 Wheelbase mm 3600
25 Ground Clearance(Under mast) mm 260
Power & Transmission 26 Battery Voltage/Capacity(5HR) VA/h 2X12/120
27 Engine Model   YC6J175-T302
28 Manufacture   YUCHAI
29 Rated Output Kw 129
30 Rated Torque N.m 710
31 No.Of Cyinder   6
32 Bore*stroke mm 102/120
33 Displacement L 6.5
34 Transmission Type   Fluid Torque Converter
35 StageFWD/RVS   2/1
  36 Operating Pressute Mpa 19

hot sale 15ton /16ton FD150 diesel forklift truck 15 ton heavy diesel forklift with cabinhot sale 15ton /16ton FD150 diesel forklift truck 15 ton heavy diesel forklift with cabinhot sale 15ton /16ton FD150 diesel forklift truck 15 ton heavy diesel forklift with cabin
