32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift

China 32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift supplier
32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift supplier 32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift supplier 32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift supplier 32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift supplier 32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift supplier

Large Image :  32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift

Product Details:

Place of Origin: China
Brand Name: BENE
Certification: ISO9001
Model Number: FD350

Payment & Shipping Terms:

Minimum Order Quantity: 1unit
Price: 150000USD---200000usd/unit
Packaging Details: nude
Delivery Time: 45days after advance payment
Payment Terms: L/C, T/T
Supply Ability: 99units per month
Contact Now
Detailed Product Description
Engine: WEICHAI Transmission: Hydraulic
Mast Height: 3500mm Load Center: 600mm

32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift



1.Adopt CUMMINS diesel engine, which features sufficient power, large torque, strong overload capacity, reliable work, and low oil consumption

2.High strength solid steel gantry fork fixed with fork with regulator.

3.Heavy duty torque converter installed for smooth rotation of power within the internal combustion engine, to rotating-driven loads. Torque converter supersedes the mechanical clutch, effectively allowing the load to be configured from the power source.
4.Fitted with handy steer with maximum freedom, provides steering conveniences.
5.An ideal operation friendly in the engineering and industrial sectors.
6.Steering axle: adopt full-hydraulic steering gear with transverse cylinder, which helps ensure flexible steering and high reliability
7.The gearbox and torque converter are of reliable quality and stable performance.
8.The transmission mode is hydraulic transmission (flexible transmission), being stable and convenient to operate.
9.Brake system is famous brand product, with reliable brake performance.

Item Specification Unit
General 1 Model   FD350
2 Power Type/model   Diesel
3 Rated Capacity Kg 35000
4 Load Center mm 1250
Dimensions 5 Lift Height mm 4000
6 Fork Size(LxWxT) mm 2400×300×120
7 Fork Spread(outside)(Min./Max) mm 980/2500
8 Mast Tilt Angle(F/R) deg 6°/12°
9 Fork Overhang mm 1220
10   Length without forks mm 7150
11 Overall Width mm 3370
12 Mast Lowered Height mm 4200
13 Overhead Guard Height mm 3690
14 Outer turning Radius   mm 6950
Performance 15 Speed(Unload/Load) Travel km/h 30/26
16 Lifting mm/s 300
17 Max.gradeability(Load) % 20
18 Max.drawbar pull(Load) KN 200
19 service Weight kg 40000
Wheels&Tires 20 Tire Front   4×16.00-25-32PR
21 Rear   2×16.00-25-32PR
22 Tread Front mm 2430
23 Rear mm 2240
24 Wheelbase mm 5000
25 Ground Clearance(Under mast) mm 360
Power & Transmission 26 Battery Voltage/Capacity(5HR) VA/h 2X12/150
27 Engine Model   WP10G240
28 Manufacture   WEICHAI
29 Rated Output Kw 178
30 Rated Torque N.m 786
31 No.Of Cyinder   6
32 Bore*stroke mm 114/135
33 Displacement L 8.3
34 Transmission Type   Fluid Torque Converter
35 StageFWD/RVS   2/1
  36 Operating Pressute Mpa 21



32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift32ton heavy duty forklift with Cummins engine 32ton container reach stacker 32ton container forklift
