log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments

China log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments supplier
log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments supplier log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments supplier log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments supplier log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments supplier log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments supplier log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments supplier

Large Image :  log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments

Product Details:

Place of Origin: China
Brand Name: BENE
Certification: ISO9001
Model Number: FD979-J

Payment & Shipping Terms:

Minimum Order Quantity: 1unit
Price: 70000-100000USD per unit
Packaging Details: nude packing
Delivery Time: in 30days
Payment Terms: T/T, L/C
Supply Ability: 999units per year
Contact Now
Detailed Product Description
Price: 100000-120000USD Engine: Cummins
Transmission: Hydraulic Load Capacity: 10000kgs

log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments



10 ton wheel loader with cummins engine FD979-J, the grapple capacity up to 10 tons, can vertically and stably clamp log, rail, steel tube and so on at mountainous area and rugged road.



Specification

Rated load 10ton

Bucket capacity 4.5 m3

Max log length 13000mm

Max log diameter 1500mm

Clamp front/rear inclination 55°/40°

Dump height 3200mm

Reach at full lift discharge 1240mm

Overall length 8980mm

Overall height 3870mm

Overall width 3120mm

Tread width 2390mm

Minimum ground clearance 450mm

Turning angle 35°

Grade ability ≥24°

Max. traction force 230KN

Hydraulic cycle time 12sec

Machine weight 31000kg



Engine Cummins 6CTA8.3 260hp



Transmission ZL70A planetary F2/R1 gearbox

Travel speed

Forward I 11km/h

Forward II 29km/h

Reverse 14.5 km/h



Hydraulic oil tank capacity 400L

Diesel fuel tank capacity 400L



Tires type 4*26.5-25-46pr

log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments

log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachmentslog wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments

log wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachmentslog wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachmentslog wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachmentslog wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachmentslog wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachmentslog wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachmentslog wheel loader with 5ton/8ton/10ton/12ton load capacity wheel loader with grapples attachments
