| Engine: | YUCHAI | Transmission: | Hydraulic |
|---|---|---|---|
| Mast Height: | 3000mm | Load Center: | 600mm |
12ton to 13ton diesel forklift 13 ton forklift truck with top quantity for sale
1.Adopt Yuchai diesel engine, which features sufficient power, large torque, strong overload capacity, reliable work, and low oil consumption
2.High strength solid steel gantry fork fixed with fork with regulator.
3.Heavy duty torque converter installed for smooth rotation of power within the internal combustion engine, to rotating-driven loads. Torque converter supersedes the mechanical clutch, effectively allowing the load to be configured from the power source.
4.Fitted with handy steer with maximum freedom, provides steering conveniences.
5.An ideal operation friendly in the engineering and industrial sectors.
6.Steering axle: adopt full-hydraulic steering gear with transverse cylinder, which helps ensure flexible steering and high reliability
7.The gearbox and torque converter are of reliable quality and stable performance.
8.The transmission mode is hydraulic transmission (flexible transmission), being stable and convenient to operate.
9.Brake system is famous brand product, with reliable brake performance.
|
FDM8120Speciflcation |
|||||
|---|---|---|---|---|---|
| General | Manufacture | FUDA | |||
| Model | FDM8120 | ||||
| Power type | Diesel | ||||
| Rated capacity | Kg | 12000 | |||
| Load center | mm | 700 | |||
| Dimensions | Life height | mm | 3000 | ||
| Free lift height | mm | 90 | |||
| Fork size | mm | 1600×180×90 | |||
| Fork distantce | Min./Max. | mm | 514/1908 | ||
| Mast tilt angle | Front/Rear | ° | 8/12 | ||
| Front overhang | mm | 780 | |||
| Overall dimensions | Length | with forks/without forks | mm | 6370/4770 | |
| width | mm | 2100/2150 | |||
| Mast lowered height | mm | 2880 | |||
| Mast extended height | mm | 4390 | |||
| Overhead guard height | mm | 2550 | |||
| Turning radius | mm | 4100 | |||
| Min.right angle aisle width | mm | 3350 | |||
| Performance | no load/full load | Trave speed | km/h | 27/24 | |
| Lifting spead | mm/sec | 300/250 | |||
| Max.grade ability | % | 18 | |||
| Max.pull force(full load) | KN | 71 | |||
| Self weight | Kg | 16000 | |||
|
Chassis |
Types | Front | 4×10.00-20 | ||
| Rear | 2×10.00-20 | ||||
| Tread | Front | mm | 1540 | ||
| Rear | mm | 1880 | |||
| wheelbase | mm | 2780 | |||
|
Min.Ground clearance (no load/full load) |
Mast | mm | 220/210 | ||
| Frame | mm | 235/230 | |||
| Drive unit & control | Battery | V/AH | 24×100×2 | ||
| Engine | Model | YC6B125-T11 | |||
| Manufacture | YUCHAI | ||||
| Rated output | Kw/rpm | 92 | |||
| Rated torque | N.m/rpm | 450/1400~1600 | |||
| NO.of cylinders | 6 | ||||
| Bore × stroke | mm | 108×125 | |||
| Displacement | L | 6.871 | |||
| Fuel tank stroke | L | 150 | |||
| Transmissions | Type | Hydraulic | |||
| Shift | Front/rear | 2/1 | |||
