chinese 12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine price list

China chinese 12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine price list supplier
chinese 12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine price list supplier chinese 12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine price list supplier chinese 12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine price list supplier chinese 12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine price list supplier

Large Image :  chinese 12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine price list

Product Details:

Place of Origin: China
Brand Name: BENE
Certification: ISO9001
Model Number: FD120

Payment & Shipping Terms:

Minimum Order Quantity: 1unit
Price: 40000USD---50000usd/unit
Packaging Details: nude
Delivery Time: 30days after payment
Payment Terms: L/C, T/T
Supply Ability: 99units per month
Contact Now
Detailed Product Description
Engine: YUCHAI Transmission: Hydraulic
Mast Height: 3000mm Load Center: 600mm

12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine for sale



1.Adopt Yuchai diesel engine, which features sufficient power, large torque, strong overload capacity, reliable work, and low oil consumption

2.High strength solid steel gantry fork fixed with fork with regulator.

3.Heavy duty torque converter installed for smooth rotation of power within the internal combustion engine, to rotating-driven loads. Torque converter supersedes the mechanical clutch, effectively allowing the load to be configured from the power source.
4.Fitted with handy steer with maximum freedom, provides steering conveniences.
5.An ideal operation friendly in the engineering and industrial sectors.
6.Steering axle: adopt full-hydraulic steering gear with transverse cylinder, which helps ensure flexible steering and high reliability
7.The gearbox and torque converter are of reliable quality and stable performance.
8.The transmission mode is hydraulic transmission (flexible transmission), being stable and convenient to operate.
9.Brake system is famous brand product, with reliable brake performance.

Item Specification Unit
General 1 Model   FD120
2 Power Type/model   Diesel
3 Rated Capacity Kg 12000
4 Load Center mm 600
Dimensions 5 Lift Height mm 3000
6 Fork Size(LxWxT) mm 1800×175×90
7 Fork Spread(outside)(Min./Max) mm 480/1960
8 Mast Tilt Angle(F/R) deg 6°/12°
9 Fork Overhang mm 750
10   Length without forks mm 4520
11 Overall Width mm 2310
12 Mast Lowered Height mm 2940
13 Overhead Guard Height mm 2720
14 Outer turning Radius   mm 4450
Performance 15 Speed(Unload/Load) Travel km/h 24/20
16 Lifting mm/s 300
17 Max.gradeability(Load) % 20
18 Max.drawbar pull(Load) KN 100
19 service Weight kg 15000
Wheels&Tires 20 Tire Front   4×11.00-20-16PR
21 Rear   2×10.00-20-16PR
22 Tread Front mm 1620
23 Rear mm 1770
24 Wheelbase mm 2950
25 Ground Clearance(Under mast) mm 290
Power & Transmission 26 Battery Voltage/Capacity(5HR) VA/h 2X12/90
27 Engine Model   YC6J150-T301
28 Manufacture   YUCHAI
29 Rated Output Kw 110
30 Rated Torque N.m 600
31 No.Of Cyinder   6
32 Bore*stroke mm 105/125
33 Displacement L 6.494
34 Transmission Type   Fluid Torque Converter
35 StageFWD/RVS   2/1
  36 Operating Pressute Mpa 19



chinese 12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine price listchinese 12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine price listchinese 12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine price listchinese 12ton/13ton/14 ton container forklift 12ton heavy duty forklift with cummins engine price list
