Product Details:
Payment & Shipping Terms:
|
Price: | 40000USD--45000USD | Engine: | Cummins |
---|---|---|---|
Transmission: | Hydraulic | Load Capacity: | 2500kgs |
Name: | 2.5ton Telehandler |
BENE 2.5 ton 3.5ton to 5ton telescopic forklift VS Manitou telehandler with 8000mm max lifting heigh
BE2508 Telescopic forklift
Specifications:
Item | Specification | Remarks |
Rated load (kg)25 | 2500 | with forks |
Operating weight(kg) | 8650 | |
Max. Lifting height of the main hook (mm) | 7605 | Distance from the main hook to the ground |
Max. lifting height of the complete arm (mm) | 8000mm | Front point hoist |
Wheel base (mm) | 2988 | |
Front tread (mm) | 1638 | |
Rear tread (mm) | 1785 | |
Min. groud clearance (mm) | 310 | |
Overall length (mm) | 5288 | Without hook |
Overall width (mm) | 2310 | |
Overall height (mm) | 2715 | |
Height of the cab (mm) | 2400 | |
Length of rear overhang (mm) | 1055 | |
Max. outreach of the main hook (mm) | 4800 | Horizontal direction |
Max. outreach of the complete arm (mm) | 7900 | Horizontal direction |
Tipping angle of hook, up/down (°) | 22°/24° | |
Tipping angle of big arm, up/down (°) | 14°/43° | |
Min. turning radius (mm) | 6800 | |
Max. gradeability (°) | ≥20% | |
Max. travelling speed (Km/h) | 25 | |
Front tyre | 11.00-20 | |
Rear tyre | 9.00-20 | |
If with fork, then the load capacity will be 2.5t |
Parameters:
No. | Name | Model | Manufacturer |
1 | Engine | 4BT3.9-C80 (60W,2200rpm) | Cummins |
2 | Frame | / | BENE |
