Home ProductsTelescopic forklift / Telehandler

3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine

A very professional company,good products and good service!

—— Kelvin ASH

It was a nice pleasant cooperation, And I hope there will be more cooperation opportunities in the future

—— Malcolm Higgins

A good team with much experience in these machines.

—— Jose E Angulo

I'm Online Chat Now

3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine

China 3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine supplier
3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine supplier 3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine supplier 3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine supplier 3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine supplier 3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine supplier 3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine supplier

Large Image :  3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine

Product Details:

Place of Origin: China
Brand Name: SOCMA
Certification: ISO9001
Model Number: HNT35-4

Payment & Shipping Terms:

Minimum Order Quantity: 1unit
Price: 45000USD--55000USD per unit
Packaging Details: nude packing
Delivery Time: in 45days
Payment Terms: T/T, L/C
Supply Ability: 999units per year
Contact Now
Detailed Product Description
Price: 50000USD--55000USD Engine: Cummins
Transmission: Hydraulic Load Capacity: 11000kgs

3.5 ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine



HNT-110 Telescopic Crane

Specifications:

Item Specification Remarks
Rated load (kg) 11000 In main hook
Operating weight(kg) 13000
Max. Lifting height of the main hook (mm) 7605 Distance from the main hook to the ground
Max. lifting height of the complete arm (mm) 10300 Front point hoist
Wheel base (mm) 2988
Front tread (mm) 1638
Rear tread (mm) 1785
Min. groud clearance (mm) 310
Overall length (mm) 5288 Without hook
Overall width (mm) 2310
Overall height (mm) 2715
Height of the cab (mm) 2400
Length of rear overhang (mm) 1055
Max. outreach of the main hook (mm) 4800 Horizontal direction
Max. outreach of the complete arm (mm) 7900 Horizontal direction
Tipping angle of hook, up/down (°) 22°/24°
Tipping angle of big arm, up/down (°) 14°/43°
Min. turning radius (mm) 6800
Max. gradeability (°) ≥20%
Max. travelling speed (Km/h) 25
Front tyre 11.00-20
Rear tyre 9.00-20
If with fork, then the load capacity will be 5t




Parameters:

No. Name Model Manufacturer
1 Engine 4BT3.9-C100 (75KW,2200rpm) DF Cummins
2 Frame / SOCMA
3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine
3.5ton telescopic forklift 3.5 ton telehandler 3.5 ton all terrain forklift with Cummins engine
