Color: | Yellow | Engine: | ISUZU C240 |
---|---|---|---|
Mast Height: | 3000mm | Transmission: | Hydraulic |
3.0ton diesel forklift with isuzu engine 3.0t forklift truck with triplex mast
Description
3.0-4.0T diesel forklift truck is well known for its good stability and flexible utility. It is usually used to lift and stack cargoes in the outdoors. Compared to gasoline engine, diesel engine possesses better power performance and low fuel charge. The engine is not easy to flame out even at low speed. It owns strong overload capacity and long-term working capacity.Our 3.0-4.0T diesel forklift trucks adopt DACHAI, YANMAR, MITSUBISHI and ISUZU engines with excellent hydraulic system. They have been proved to be economic, powerful, safe, durable and reliable.
Parameters
SPECIFICATION | Item | FD30T/C | FD35T/C | FD40T/C | |
Load capacity | kg | 3000 | 3500 | 4000 | |
Load center | mm | 500 | |||
DIMENSIONS | Max. lifting height(VM300) | mm | 3000 | ||
Free lift(VM300) | mm | 150 | |||
Fork size (L×W×T) | mm | 1070*125*45 | 1070*125*50 | 1070*150*50 | |
Overall length(without fork) | mm | 2705 | 2760 | 2870 | |
Total width | mm | 1225 | 1285 | 1365 | |
Mast height (fork lowering) | mm | 2075 | 2150 | ||
Overall height fork raised | mm | 4250 | |||
Height to head guard | mm | 2140 | |||
Truck weight | kg | 4380 | 4780 | 5050 | |
TIRES | front/rear | 2/2 | |||
front axle | 28*9-15-12PR | 250-15-16PR | |||
rear axle | 6.50-10-10PR | ||||
ENGINE | Model | MITSUBISHI S4S | ISUZU C240 | ISUZU 4JG2 | |
Rated power | kw/rpm | 35.4/2250 | 34.3/2500 | 44.8/2450 | |
Rated torque | Nm/rpm | 170/1700 | 138/1800 | 186/1800 | |
Number of cylinders | 4 | 4 | 4 | ||
Dislacement | L | 3.059 | 2.369 | 3.059 |
Optional Engine
FG30,FG35: NISSAN K25
Components
3.0-4.0T diesel counterbalance forklift truck is mainly composed of engine, transmission, operating control device, working device (inside and outside door frame, fork mounting, pallet fork, lifting chain, roller, pulley and others), hydraulic system and electrical system.
FAQ
1.What's the Certificate do you have?
BENE workshop meet with the ISO9001 Quality System. And all of our products are with CE certificate. EPA approval can be available if needed.
2. Can you customize and design as the clients' requirement?
BENE will try our best to meet all kinds of clients' special requirements. And for new products that have not been into the market yet, we have our technical team to help the clients.
3. How long is the warranty of your products?
All of products are with 1 year / 2000 working hours subject to the first.
4. Can you produce the products labeled with the client's brand?
Yes, we do!
With the authorization of the brand, we can OEM for our clients.
5. What's the payment terms do you accept?
Normally we accept 30% deposit, 70%balance before delivery, it can be negotible according to the actual situation.
6. Delivery date:
If clients need normal products, we will deliver the products within 30 days. If clients need customerized products, the delivery date depend on the requirements.
